Models
Just a few of our most common mast models used in various industries
VMX 3/12/1.7m
Ideal for orchard use, featuring a 3-stage design for a compact mast height, a heavy-duty 1.2 tonne lift capacity up to 1.7m, and the ability to move around and under trees without damaging fruit. It can lift up to 2 bins to truck deck height and comes standard with 600mm freelift travel for added versatility.
VMX 2/12/2.7m
Ideal for grapes, orchards, or general use, offering a heavy-duty 1.2 tonne lift capacity up to 2.7m, perfect for applications where height is not restricted.
VMX 2/15/3.0m
Ideal for cropping use, featuring a 2-stage design, heavy-duty 1.5 tonne lift capacity to 3.0m, and high ground clearance of 450mm, making it perfect for applications where height is not restricted.
Mounting and Control Options
Mounting and control option available, depending on the configuration of your tractor/ forklift
+ Fixed Front Mount Subframe
We manufacture subframes to suit any specific tractor model/ make.
+ Linkage Mounted
We offer kits to fit front or rear linkage hitch systems. Hydraulic Tilt and Sideshift options.
+ IMAX Mounting System
The unique IMAX system integrates the mountings, tilting system and sideshift mechanism in one ultra compact unit, virtually hidden by the front of the tractor and giving almost unobstructed vision down the side of the bonnet.
+ Joystick Control
We offer 2 function or 3rd service joystick control. (Depending on tractor configuration)
+ Control Valve Banks
For non-cab tractors, we offer a 2 or 3 bank control valve option.
+ Existing Controls
We can utilise existing hydraulic controls. (Depending on tractor configuration)
Specifications
Overall forklift specs
Lift Height range 1.1m – 4.1m
Lift capacity options
600kg, 1200kg, 1500kg
Hydraulic capacity Required
12-60 litres/min, 2500-3000psi
Forklift Brochure Available Sizes
| Model | 2/12/1.1m | 2/12/1.4m | 2/12/1.7m | 2/12/2.7m | 2/12/3.0m | 3/12/1.7m | 3/12/2.2m | 3/12/2.5m | 3/15/3.0m | 3/15/2.5m |
|---|---|---|---|---|---|---|---|---|---|---|
| Stages | 2 | 2 | 2 | 2 | 2 | 3 | 3 | 3 | 2 | 3 |
| Capacity | 1200kg | 1200kg | 1200kg | 1200kg | 1200kg | 1200kg | 1200kg | 1200kg | 1500kg | 1500kg |
| Lift height | 1120mm | 1420mm | 1720mm | 2700mm | 3000mm | 1720mm | 2220mm | 2550mm | 3000mm | 2550mm |
| Freelift | None | None | None | None | None | 600mm | 710mm | 820mm | None | 820mm |
| Closed mounted height | 1140mm | 1280mm | 1430mm | 1924mm | 2170mm | 1140mm | 1280mm | 1390mm | 2220mm | 1390mm |
| Ground clearance height | 150mm | 150mm | 150mm | 300mm | 300mm | 150mm | 150mm | 150mm | 450mm | 150mm |
| Optional ground clearance | 300mm | 300mm | 300mm | 450mm | 450mm | 300mm | 300mm | 300mm | 600mm | 300mm |
| Use | Orchard | Orchard | Orchard | General | General | Orchard | Orchard | Orchard | Cropping | Orchard |
| Model Key: | 2 = 2 Stage | 3 = 3 Stage | / 12 = 1200kgs | 15 = 1500kgs | / 1.1 = 1.1m Lift height |
FAQ
-
Do you sell through dealers?
Yes we do. We have multiple dealers around New Zealand and Australia. Contact us to find your nearest dealer.
-
Do these work with any tractor?
Yes we have jigs for common model tractors, and can retrofit subframes to any other model/ make.
-
Do you sell replacement parts?
Yes, we have replacement parts in stock.
Do you have any questions about our VMX Forklifts? Call us on +64 6 879 4992
