Models
We have both double and single-sided options available.
Double-sided Vineyard / Orchard Sweep
Single-sided Sweep
Product Features
Landquip have been designing and manufacturing pruning sweep machines for over 30 years.
Versatile Mounting Options
Choose from 3-point linkage, fixed mount, or ERO plate for flexible installation.
Adaptable to Any Row Spacing
Generous side-shift travel accommodates most vineyard and orchard row widths.
Breakaway Spring Protection
Prevents damage to posts, vines, trees, and the machine with a built-in breakaway spring system.
Fully Adjustable Design
Offers two-axis angle adjustment, along with lift and side-shift capabilities for precise control.
Available Sizes
Pruning Sweeps | Single Fixed | Single Manual | Single Hydraulic | Double Narrow | Double Wide | Double Wide 3PL | Double Narrow Fixed |
---|---|---|---|---|---|---|---|
Max Row Centers Width | Unlimited | Unlimited | Unlimited | 2.5m | 2.2m | 2.5m | 2.2m |
Min Row Centers Width | 2.5m | 2.0m | 2.0m | 3.0m | 1.7m | 3.0m | 2.2m |
Min Oil Flow Required | 40lpm | 40lpm | 40lpm | 40lpm | 40lpm | 40lpm | 40lpm |
Hydraulic Circuits Required | 2 | 2 | 3 | 3 | 3 | 2 | 2 |
Breakaway Spring | No | No | No | Yes | Yes | Yes | Yes |
In Use
“The biggest challenge we have in our business is labor. Any machine we can utilize that creates efficiency in productivity is really important. We’re running 38 canopy hectares with four different tree sizes, so having the hydraulic sweeper that we can set up at the start of the season and move in and out of each block with minimal change.”
Andrew Douglas Manager at Douglas Fruit Company
FAQ
-
Do you ship internationally?
We ship to Australia, talk to us about where your nearest dealer is located.
-
Can these be mounted to any tractor?
These can be mounted to almost any orchard/vineyard style, contact us with details about your tractor to find out.
-
Can the different style heads be swapped over?
Yes all have a universal drive plate that can be used for all head styles.
