What makes Landquip mowers ‘best of breed"
Unique features that make Landquip Vineyard/Orchard Mowers superior.
Strength
We know that the nature of mowing orchards, and particularly vineyards in New Zealand and Australia is extremely hard on mower body’s due to often hard and stony ground. As a result of customer and dealer feedback, we have standardized our entire V-series range to include an 8mm thick deck. Body design also features an under-body brace which keeps the gearbox mounting area rigid and ensures the drive train stays aligned for a longer lifetime.
Simplicity
Customers and dealers appreciate the simplicity of our design. We've found the right balance— not too rigid to crack and not too flexible to loosen bolts. This ensures durability and reliability.
Performance
When mowing vineyards and orchards, performance matters most. Our high-speed mowers provide not only a fine cut, but significant savings on labor and fuel costs.
Simple and heavy-duty front and rear rollers
We use large diameter heavy-duty pipe for both the front and rear rollers, we use strong & simple 2-bolt flange greaseable bearing housings for the front rollers.
Effective side discharge option
The side discharge option ensures no harm to irrigation lines. This is achieved through the downward-angled 'ramp' we weld to the underside of the body, directing the mowing debris into the soil directly beneath the trees/vines.
Easy-clean design
The mower design enables quick and easy cleaning of grass clippings, a crucial feature given that acidic juice from these clippings can lead to rust on the mower body.
Models
| Model | V1600 | V1800 | V2000 | V2100 | V2400 | V2700 | V2850 | V3000 |
|---|---|---|---|---|---|---|---|---|
| Weight | 480 kg | 520 kg | 550 kg | 630 kg | 650 kg | 2.5m | 690 kg | 720 kg |
| Overall Width | 1632mm | 1832mm | 2032mm | 2132mm | 2432mm | 3.0m | 2882mm | 3032mm |
| Overall Length | 1510mm | 1530mm | 1550mm | 1580mm | 2425mm | 40lpm | 1480mm | 1500mm |
| Overall Height | 1000mm | 1000mm | 1000mm | 1000mm | 1000mm | 1000mm | 1000mm | 1000mm |
| Ground to Mower Deck | 300mm | 300mm | 300mm | 300mm | 300mm | 300mm | 300mm | 300mm |
| Cutting Width | 1570mm | 1770mm | 1970mm | 2070mm | 2315mm | 2670mm | 2800mm | 2970mm |
| Cutting Height | 30-120mm | 30-120mm | 30-120mm | 30-120mm | 30-120mm | 30-120mm | 30-120mm | 30-120mm |
| Number of Rotors | 2 | 2 | 2 | 2 | 2 | 3 | 3 | 3 |
| Number of Blades | 4 | 4 | 4 | 4 | 4 | 6 | 6 | 6 |
| Speed of Blades | 14,800 f/m | 11,800 ft/m | 13,100 ft/m | 16,200 ft/m | 15,600 f/m | 12,500 ft/m | 12,650 ft/m | 13,000 ft/m |
| Maximum Power of Tractor | 75 HP | 90 HP | 90 HP | 90 HP | 90 HP | 150 HP | 150 HP | 150 HP |
| PTO Revs | 540 RPM | 540 RPM | 540 RPM | 540 RPM | 540 RPM | 540 RPM | 540 RPM | 540 RPM |
| NOTE: Cutting area is 20-40mm less than stated mower width |
Add-On Options
The following options can be added to your choice of V-series mower
+ Front rollers
Rather than using the tractor linkage system, front rollers take the weight of the front of the mower. These rollers also guarantee that the mower follows the terrain's contours, resulting in a consistently uniform mowing outcome. Our design boasts a remarkable blend of simplicity and robustness, using top quality Japanese bearings capable of withstanding lateral pressure, which comes into play if the mower is inadvertently left down while making a turn.
+ Chain guard
Enhance safety with our robust galvanized chain guard, designed to prevent debris from being thrown forward.
+ Fling tips
These tips are designed for an extra-low, fine cut, easily reversible and replaceable as they wear.
+ Mulching blade kit
Double down on your asset by adding a heavy-duty 3-blade mulching kit so you can convert the mower into a mulcher.
+ Wheel kit
Wheels are often favoured over rollers for their smoother ride and minimized ground scouring during turns when the mower is in the down position. Featuring a full 360 degrees of swivel, our heavy-duty hub/stub is equipped with tapered bearings to ensure optimal performance and durability.
In Use
“I manage Accolade Wines in Central Otago, running 115 hectares of tough, rocky soil. We’ve used this mower for 4 years and love its balance, fast cutters, and great finish—even on weedy grass. It’s hardy, low-maintenance, and hassle-free, perfect for our needs.”
Warranty
All Landquip Mowers come with Landquip’s renowned ‘Best of breed’ – 2 year warranty
- Covers any defective workmanship on all parts and components of the Mower
FAQ
-
Do you ship to Australia?
Yes, we do. We have multiple dealers across Australia. Contact us to find out your closest dealer.
-
Do you make custom design?
Not generally, however we’ll consider anything, please don’t hesitate to contact us.
-
Do you sell spare parts?
Yes we have a special ‘spare parts’ department.
Do you have any questions about Landquip Mowers? Call us on +64 6 879 4992
